LIQUID GRANITE

Liquid Granite

Our water based multi color granite coating has been applied on projects around the world. We have had success in emulating actual stone at a fraction of the cost and time required of real stone products. We give the designer great flexibility in creating designs that can adapt to the building concept to increase a wide range of flexibility. Tech Stone can adhere to concrete, metal or wood substrates allowing a vast range of applications available. Take a look at some of our sample projects and contact us about a consultation for your upcoming project.

Application

  • Building Facade
  • Granite coating exterior wall
  • Various style of beam and column. Example: Roman column
  • Suitable for a variety of surfaces and bases. Examples: cement base, metal plates such as aluminum wood,tile and glass etc.

Product Structure

  • Clear Sealer
  • Stone Pattern
  • Base Coat
  • Stone Primer
  • Original Substrate/base

Primer

  • Apply with spray or roller
  • Amount use: 0.08-0.12 kg per m2
  • Allow 10-15% water content
  • Minimum of 3 hours drying after application

Process Requirements

Applicable Surface Requirement

  • Flatness allow ± 3mm
  • Less than 10 pH
  • Water content < 10%
  • Intensity/Strength ≥ 5 kgf/cm²
  • Construction under low temperature environment will avoid film-formation resulting in crack

Environment Requirements

  • Temperature: 5 to 40 degree Celsiusa
  • Humidity < 10
  • Wind < 5 m/s
  • Avoid construction under situations:
  • Rain, Frost, Fog, Snow
  • Windy: over 5 m/s

Base Coat

  • Apply with lacquer used spray or roller
  • Consumption: 0.8-1.5 kg per m2
  • Allow minimum of 24 hours drying after application

Stone Pattern

Clear Sealant

  • Apply with spray gun or roller
  • Consumption: 0.08-0.15 kg per m2 of water content
  • Well-stir before application
  • Allow minimum of 12 hours drying after application

Aging resistance comparison bar chart

The average standard aging resistance time length is 250 hours, which is equivalent to 3 years of use.

Crack Resistant

  • Applicable on variously architectural design with least limitation which is suitable for numerous surfaces of different materials.
  • Contain over 80 of nature highly elastic materials giving it the ability to cover tiny cracking on the walls.

Anti-cracking testing result

extendibility: 1mm material can be extended to 3.48mm maximum.

Stain Resistant

Expressively stain and water resistant that prevent water or rain from permeating into matrix to avoid the growth of fungi, alga and efflorescence
